POW-M25/M35/M45-PRO Solar Charge Controller

Introduction

The POW-M25/M35/M45-PRO solar charge controller is designed with innovative maximum power point tracking (MPPT) technology, specifically for solar systems. Experience conversion efficiency up to 98% for optimal performance.

Features

  • Available in 25A, 35A, and 45A models with MPPT technology.
  • Advanced MPPT tracking efficiency up to 99% with peak conversion efficiency up to 97%.
  • Equipped with a high-performance DSP controller.
  • Automatically adapts to 12V/24V battery banks.
  • 3-stage charging enhances battery performance.
  • Integrated features include overcharge protection, reverse polarity protection, and current limiting protection.
  • Over-temperature protection and troubleshooting function.
  • Easy to mount and install.

Specifications

Model 25A 35A 45A
Max. PV Open-Circuit Voltage 100V 100V 100V
Max. Input Power for 12V System 300W 600W 420W
Max. Input Power for 24V System 840W 540W 1080W
Charging Technology MPPT MPPT MPPT
Charging Algorithm 3 Stages 3 Stages 3 Stages
Nominal System Voltage 12V/24V 12V/24V 12V/24V
Battery Voltage Range 9~30V 9~30V 9~30V
Rated Charging Current 25A 35A 45A
Conversion Efficiency ≤98% ≤98% ≤98%
Max. Power Tracking Efficiency >99% >99% >99%
Temperature Compensation -3mV/℃/2V (default)
Self-Consumption 44mA/12V; 26mA/24V
Rated DC Output Current 15A 20A 25A
IP Class IP32 IP32 IP32
Operating Temperature Range -35℃~+45℃
Humidity Range ≤95% Non-condensing
Dimensions (LxWxH) 160x115x51mm 195x135x65mm 195x135x65mm
Net Weight 500g 900g 1035g

Package Includes

  • 1 x Power Supply (25A/35A/45A optional)
