Programmable DC Electronic Load ET5410A+ Digital Battery Tester Load Meter

ET54A+ Programmable DC Electronic Load

The ET54A+ programmable DC electronic load offers outstanding performance, boasting a high resolution of 1mV/1mA. It is versatile for testing various devices such as chargers, switching power supplies, linear power supplies, and batteries, making it essential for production lines and research and development sectors.

Key Features

• User-Friendly Design:
  • Features a 2.8-inch TFT LCD screen with both Chinese and English display options.
  • Simple and intuitive interface for easy operation.
  • Includes a key lock function to prevent accidental operations.
• High Performance Load:
  • Supports CC, CV, CR, CP, and combinations of these modes for versatile testing.
  • Includes professional modes for testing batteries, LEDs, dynamic output performance, power output continuity, and short circuits.
  • Enables battery/power internal resistance testing and conformity testing.
  • Built-in buzzer alarm and data storage in case of power failure.
  • Remote operation via USB, with software support for remote compensation.
• Multiple Safety Protections:
  • Protects against overcurrent, overvoltage, overpower, and overheating, with adjustable parameters for overcurrent and overvoltage.
  • Smart fan speed control minimizes noise.
  • Provides input polarity reverse prompt.

General Technical Specifications

• Power Supply Voltage: 100Vac~240Vac, 50/60Hz
• Display: 2.8-inch TFT LCD screen with a resolution of 320×240
• Operating Temperature: 0℃ to 40℃
• Storage Temperature: -10℃ to 70℃
• Relative Humidity: Specified based on usage
• Interface: Standard USB
• Dimensions: 90mm × 190mm × 300mm (Width × Height × Depth)
• Weight: 2.9kg
