ER32 Spring Collet 3-18MM for CNC Milling Lathe Tool - 1PC Set

Machifit ER32 2-20mm Spring Collet Chuck for CNC Milling Lathe Tools

Specifications:

• Model: ER32
• Material: 20Mn
• Hardness: HRC56-60
• Taper degree: 16°
• Total height: 40mm
• Outer diameter (Max): 32mm
• Gripping Range: 3mm to 18mm (3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18mm)
• Quantity: 1 PC

Key Features:

• ER32 precision spring collet.
• Widely used in boring, milling, drilling, tapping, CNC sculpting, and other processing operations.
• Compatible with CNC tool holders.
• Offers high clamping force, wide clamping range, and excellent accuracy.

Installation Instructions:

1. Insert the chuck into the pressure cap and carefully rotate the spring until the eccentric part of the pressure cap aligns with the spring groove. Apply equal force along the arrow direction to securely fit the spring.
2. Attach the spring and cap assembly onto the chuck body or spindle. After cleaning the cylindrical shank, insert it into the clamping hole. Use a wrench to tighten the pressure cap, ensuring the tool is securely clamped before use. Note: Avoid tightening the pressure cap without a tool to prevent damage to the clamp spring.
3. To remove, use a wrench to loosen the pressure cap, then extract the chuck or tool. Push out the spring in the direction of the arrow and replace it as needed.

Package Contents:

• 1 x ER32 Collet

Note: Package includes one collet only.
