ASMC-04A High Torque Digital Industrial Servo Motor for Model Aircraft and Robotics

ASMC-04A High Torque Digital Industrial Servo Motor for Model Aircraft and Robotics

Regular price $37.99 USD
Regular price $0.00 USD Sale price $37.99 USD
Sale Sold out
Shipping calculated at checkout.

Shipping Icon Estimated Delivery: -

Lock Icon
Guaranteed secure & safe checkout.
Payment Logos
ASMC-04A Steering Gear

ASMC-04A Steering Gear

Specifications:

  • Model: ASMC-04A
  • Working Voltage: 12V to 24V (DC)
  • No-load Rotation Current: Less than 500mA
  • Maximum Torque:
    • 110kg.cm (24V)
    • 1078N.cm (24V)
    • 55kg.cm (12V)
    • 539N.cm (12V)
  • Angular Velocity:
    • 0.12s/60° at 24V
    • 0.24s/60° at 12V
  • Rotation Angle: 300° MAX (0 to 300° electronic limit adjustable)
  • Input Mode: Pulse signal (remote control, multi-channel steering gear controller, microcontroller) or analog voltage signal (potentiometer)
  • Pulse Signal Input Range: 0.5ms-2.5ms (suitable for all "multi-channel steering gear controllers", "1ms-2ms model aircraft remote controls", "microcontroller programming Arduino", etc.)
  • Voltage Signal Input Range: 0V to +5V
  • Control Accuracy: 0.32°
  • Weight: 530g
  • Gear Material: Steel
  • Overall Dimensions: 95.5mm x 60.5mm x 102.6mm

Features:

  1. High power and high torque control suitable for medium and large-sized robots.
  2. Wide working voltage range from 12V to 24V with a no-load rotary current of less than 500mA.
  3. Superior maximum torque output of up to 110kg.cm at 24V.
  4. Adjustable electro limit rotation angle from 0 to 300° MAX.
  5. Built with robust, high-quality steel gear and optimized for control accuracy of 0.32°.

Package Includes:

  • 1x ASMC-04A Steering Gear
  • 1x 20cm Signal Cable
