Machifit DC 12V Reduction Gear Motor

Optimized for Smart Door Locks, Meters, and Security Cameras

Product Specifications

• Name: Reduction Gear Motor
• Model Number: 16GA050
• Material: 304 Stainless Steel
• Color: Silver
• Rated Voltage: DC 12V
• Size: 16mm × 16mm × 40mm
• Total Length: 47mm
• Body Length: 40mm
• Shaft Length: 10mm
• Shaft Diameter: 3mm
• Quantity: 1 Pc

Performance Details

Voltage	Gear Ratio	No-Load Speed (RPM)	No-Load Current (mA)	Load Speed (RPM)	Load Current (mA)	Load Torque (g.cm)	Stall Current (A)	Stall Torque (KG.CM)
12V	1:330	30	≤50	27	≤70	560	≤1.1	7.4
12V	1:150	60	≤70	56	≤100	480	≤1.1	6.4
12V	1:100	100	≤50	83	≤85	340	≤1.1	5.0
12V	1:80	150	≤50	132	≤85	320	≤1.1	5.2
12V	1:62.5	200	≤80	165	≤105	280	≤1.1	4.65
12V	1:40	300	≤50	234	≤85	210	≤1.1	4.4
12V	1:30	400	≤70	322	≤145	180	≤1.1	3.85
12V	1:24	500	≤90	416	≤145	165	≤1.1	3.6
12V	1:20	600	≤90	505	≤145	160	≤1.1	3.6
12V	1:16	800	≤90	688	≤145	145	≤1.1	3.4

Features

• Perfect for applications such as door locks, meters, security cameras, micro robots, and medical equipment.
• High efficiency with low noise operation and excellent sensitivity.
• Long-lasting performance with stable operations and minimal speed fluctuations.
• Equipped with a high-precision gear reducer, ideal for automatic adjustment, drive, and control servo systems.
• Outstanding energy-saving benefits, with superior control and drag capabilities.

Package Includes

1 Pc × Reduction Gear Motor
