PDS138 Mini Digital Oscilloscope - 2.5MHz Sampling Rate, 200kHz Bandwidth, 80kHz PWM Support for DIY Electronic Repair

Delivery Options

Type 1:

• 1 x Host
• 1 pair of test clips

OR

Type 2:

• 1 x Host
• 1 pair of test clips
• 1 x 10X Test Probe

Features

• 2.5MHz sampling rate, actual bandwidth 200KHz
• Analog bandwidth: 1MHz (sine wave)
• Complete triggering function: single time, normal, automatic
• Measures up to ± 400V voltage signals
• Efficient one-key AUTO for quick waveform display
• One button waveform saving function

Specifications

• Sampling rate: 2.5MHz
• Analog bandwidth: 1MHz (sine wave)
• Actual bandwidth: 200KHz
• Measuring voltage: X1/± 40V, X10/± 400V
• Input impedance: 1M Ω
• Storage depth: 1Kb
• Parameter display: 12 types
• PWM output: frequency 1K~80KHz, duty cycle 0~100%, output voltage 3.3V
• Function waveform: 17 waveforms
• Output frequency: 1~1KHz Voltage range Vpp 0~3.3V (not adjustable)
• Display: 2.4 inch TFT, 320 * 240 resolution
• Charging voltage: 5V
• Battery capacity: 600mA/h 3.7V
• Upper computer: temporarily not supported
• Firmware upgrade: supported
• Size: 50cm wide and 100cm long (excluding BNC head)
• Weight: 180g (only DSO)
