VI Curve Tester

Features:

• VI curve analysis, also known as ASA, involves no circuit principle and does not require the circuit to be in a working state, making it ideal for fault detection of circuit boards that are detached from equipment, without the need for online detection.
• Absolutely forbidden to electrify or measure undischarged capacitance to ensure safety.
• Since the circuit board does not need power, it enhances safety.
• Device functions on the circuit board are not involved, allowing testing of any device types: digital, analog, digital-analog mixed, known or unknown (dedicated, programmable), etc.
• Testing is performed via circuit node (device pin), not limited by component packaging.
• ASA technology can also assess the quality of large-scale, complex, or unknown integrated devices, especially when other conditions are limited.
• Convenient and intuitive for detecting the function of discrete components.

VI and Multimeter Resistance Method Type:

• Unlike multimeter resistance with low voltage, this instrument uses AC signals to evoke circuit nodes.
• Adjustable amplitude and frequency allow setting amplitude close to working voltage for more realistic measurements.
• Identify fault nodes through comparison.
• Component-friendly; limited current prevents damage or adverse impact.
• Proven fast and effective fault diagnosis technology.

Specifications:

• 1.3 inch OLED display
• Built-in battery, 3000mAh
• 4-gear voltage adjustable (0.6V, 4V, 8V, 16V)
• 4 test frequencies (60Hz, 400Hz, 2000Hz)
• Curve movement: Yes
• Scan function: Yes
• True dual channel: Yes
• Simultaneous display: Yes
• Program control: Yes
• Host size: 14.5 x 8.2 x 4 cm
• Host weight: 218g

Note: Discharge before measurement to prevent instrument damage.

Package Includes:

• 1 x VI Curve Tester
• 2 x BNC cables
• 2 x Test leads
• 1 x Power cable
