Specifications:

• Form Factor: PI-co ITX (2.5 inch, 92 × 62mm)
• Display Outputs:
  • 1x High Definition Multimedia Interface 2.1 (up to 8K@60FPS)
  • 1x USB Type-C with Demand Paging (up to 8K@30FPS)
  • 1x MIPI DSI (up to 4K@60FPS)
• Processing Unit (SOC): RockChip RK3588
• CPU: RK3588 Quad-Core Cortex-A76 @ 2.4GHz + Quad-Core Cortex-A55 @ 1.8GHz, 8nm process
• GPU: Mali-G610 MP4, supports OpenGL ES3.2/OpenCL2.2/Vulkan1.1
• NPU: 6TOPS@INT8 (3NPU cores)
• VPU/Codec:
  • Hardware Decode: 8K@60fps H.265/VP9/AVS2, 8K@30fps H.264 AVC/MVC, 4K@60fps AVI, 1080P@60fps MPEG-2/-1/VC-1/VP8
  • Hardware Encode: 8K@30fps H.265/H.264
• ISP: Integrated 48MP ISP with HDR & 3DNR
• RAM: Up to 32GB 64bit LPDDR4/LPDDR4x, default 8GB LPDDR4x
• Flash: 32GB/64GB/128GB eMMC with MicroSD card expansion, default 64GB eMMC
• PCIe: 1x M.2 Key M (PCIe 3.0 4-lanes), default 2280
• Networking: 2x 2.5G Ethernet, IEEE 802.11a/b/g/n/ac/ax Wi-Fi 6 and BT5 (AP6275P)
• Video In/Out:
  • Video Out: 1x HDMI 2.1, 1x MIPI DSI up to 4K, 1x DP1.4
  • Video In: 2x 2-lane MIPI CSI
• Audio: HDMI audio, HP audio, Type-C 3.1 audio
• USB Ports:
  • 1x USB 3.0 (up to 5Gbps)
  • 1x USB Type-C 3.1 (DP1.4/OTG)
  • 1x USB 2.0 High/Full/Low-Speed modes
• 40-Pin Header: Compatible with Raspberry Pi header, supports multiple interfaces
• Other Features: 5V fan interface, low power RTC chip, LEDs for system status
• Power Input: USB Type-C PD 2.0, 9V/2A, 12V/2A, 15V/2A
• Buttons: PWRON, Reset, Maskrom
• OS Support: Android 12.0, Debian 11, Buildroot, with support for 3rd Party OS like Armbian, Ubuntu, Kylin OS
• Dimensions: 92 mm x 62 mm
• Operating Temperature: 0℃~85℃
