ANENG CM81 Digital Clamp Meter - 6000 Counts, Auto Range, NCV, DC/AC Voltage, Current, Resistance, Frequency, Capacitance Tester

Features:

• High-Precision Clamp: Accurately measures induction with a jaw opening diameter of 36mm for precise clamping.
• Durable Test Pens: Includes a 1000V/10A test pen with an overall length of 95cm, made from PVC and brass for safety and durability.
• Ergonomic Design: Soft silicone buttons offer a comfortable touch with a tactile pause, enhancing ease of use.
• Clear LCD Display: High-definition backlit screen ensures clear readings, with increased precision for larger counts.
• Versatile Measurements: Capable of measuring various electronic components, fulfilling diverse functional needs.
• LED Flashlight: Built-in LED lighting aids measurement in dark environments, reducing the risk of electric shock.
• Non-Invasive AC Current Measurement: Measures 600A AC current without wire puncture, using a high-precision induction clamp head.

Functionality:

• AC Voltage: 1V-600V with precision of ±(1.5%+8d)
• DC Voltage: 1V-600V with precision of ±(1.2%+5d)
• AC Current: 1A-600A with precision of ±(2.8%+8d)
• Resistance: 0Ω-60MΩ with precision of ±(1.2%+5d)
• Capacity: 100P-40mF with precision of ±(6%+10d)
• Frequency: 10Hz-20MHz with precision of ±(4.0%+10d)

Additional Features:

• NCV Support
• Auto Shutdown
• Data Retention Function
• Low Battery Indicator
• Diode and Buzzer Testing
• Real-Time Temperature Monitoring
• Automatic Range Adjustment

Specifications:

• Power Source: 2x AAA batteries (not included)
• Material: ABS
• Measurement Capacity: 6000 counts
• Jaw Opening Size: 36mm/1.41in
• Test Pen Length: 95cm

Package Includes:

• 1 x Digital Multimeter (Battery not included)
• 2 x Test Leads
• 1 x User Manual
