Product Description

1. Voltage Measurement

• Range: DC8-100V
• Display Formats:
  • <10V: e.g., 9.99V
  • <100V: e.g., 99.9V
  • ≥100V: OL
• Accuracy: ±1%

2. Percentage Range

• Range: 0%～100%
• Display Formats:
  • <10%: e.g., 9%
  • <100%: e.g., 99%
  • 100%: 100%

3. Battery Symbol

• Graphical Representation: Five cell symbols, each representing 20%
• Display Format:
  • SOC >90%: Display full cells
  • 80%<SOC ≤90%: First cell flickers
  • SOC ≤80%: Display four cells
  • 60%<SOC≤70%: Second cell flickers

Additional Functions

• Display Control: Short press the key to turn on or off the LCD display.
• Set Full/Cut-off Voltage:
  • Adjust the full and cut-off voltage as per battery specifications before use.
  • Factory default: Full voltage 60V, cut-off voltage 47.5V.
  • Note: Full/Cut-off voltage settings limited to 50 times.

  Steps to set:

  1. Long press the key to enter setup mode (60.0V H for full). Release the key.
  2. Adjust the values by short pressing the key. Long press to save and exit.
• Calibration:
  • All units are pre-calibrated. For deviations, recalibration is possible.
  • Steps:
    1. Power off the meter and long press the key.
    2. Input standard DC 20V voltage.
    3. Successful calibration is indicated by "CAL → PASS".
• Waterproof Function: The panel includes a sealing ring for splash-proof protection post-installation.

Package Includes:

• 1 x Capacity Tester
