MAKA MK2301 7-in-1 Precision Measurement Device: Temperature, Distance, Angle Detection with 1024 Pixel Infrared & Visible Imaging for Thermal Analysis

MAKA Multifunctional Measurement Device

Features:

• Combines measurement, distance, and angle testing in one versatile device.
• Temperature measurement range from -20℃ to +1000℃ with an accuracy of ±3K or ±3%, perfect for monitoring environmental temperatures between 15-50℃ and object temperatures between 15-200℃.
• Equipped with a 300,000-pixel visible light lens and a fixed-focus infrared resolution of 1024 pixels (32×32) for high-definition image capture.
• Built-in storage of 8M (7.8M available) to store up to 52 photos and supports a maximum of 32G Micro SD card expansion.
• Offers various display options with an infrared and visible light fusion of 0% full thermal imaging, 25%, 50%, 75%, and 100% (all visible light).

Specifications:

• Brand: MAKA
• Temperature Measurement Range: -20℃~+1000℃
• Accuracy: ±3K or ±3%
• Emissivity: Default 0.95 (adjustable between 0.01-1)
• Response Time: 250ms
• Infrared Frequency Band: 8um-14um
• Visible Light Lens: 300,000 Pixels
• Infrared Image Resolution: 1024 pixels (32×32)
• Display Type: 2.4" TFT LCD 240×320 Pixels
• Built-in Storage: 8M (7.8M available)
• Max Storage Support: 32G Micro SD Card (FAT32 format)

Package Included:

• 1 × MK2301
• 1 × Thermal Imaging Module
• 1 × USB Data Cable
• 1 × Detachable Bracket
