Wired High Sensitivity Glass Break Sensor Alarm for Home Security System

Note: This wired glass break detector must be used with an existing alarm system.

Features

• Powered by an 8/12 bit microprocessor-controlled digital signal processor (8MHz)
• Capable of distinguishing glass break sounds from other sounds based on frequency
• Unaffected by sounds from pets or other noises outside its frequency range
• Sends an alert signal to the main alarm system unit upon detecting a glass break sound
• Adjustable sensitivity: covers up to 9m (30ft) when installed in a high position, and up to 4.5m (15ft) when installed in a lower position
• Equipped with 7 frequency digital filters, digital amplifier gain, and frequency fluctuation assessment
• Designed to cover a large area of windows; mount on the ceiling or wall near a window
• High immunity to RFI and EMI signals

Specifications

• Digital Processor: 8/12 bits 8MHz
• Power Supply: DC 9-16V, 17mA
• Alarm Output: DC28V 0.15A, Normally closed
• Tamper Switch: DC28V 0.15A, Normally closed, cover removed open circuit
• Protection Range: Maximum sensitivity up to 9 meters
• Sensitivity: Continuously adjustable
• Detects glass of any size
• Detecting: Green LED indicator
• Alarming: Red LED indicator for 3 seconds
• Material: ABS plastic
• Operating Temperature: -20°C to 50°C
• Operating Humidity: 95%
• Item Dimensions: Approx. 9 x 6.8 x 2.5 cm (L x W x H)
• Item Weight: Approx. 45g / 1.6oz

Package Information

• Package Size: Approx. 9.5 x 7 x 3.3 cm / 3.7 x 2.8 x 1.3 in
• Package Weight: Approx. 54g / 1.9oz

Package List

• 1 x Wired Glass Sensor (no cable included)
