XH-M548 TPA3116D2 Bluetooth 5.0 Dual Channel 240W High-Power Digital Audio Amplifier Board

Features

• Powered by the TPA3116D2 next-generation digital chip.
• Incorporates CSR8635 Bluetooth module, compatible with version 4.0.
• Includes NE5532 dual op amps for superior audio performance.
• Equipped with an efficient array radiator for optimal cooling.

Specifications

• Chip Type: TPA3116D2
• Bluetooth Module: BTM835/CSR8635 (version 4.0)
• Transmission Distance: Up to 10 meters (without interference)
• Supply Voltage: DC12-24V
• Supply Current: Requires more than 3A
• Output Power: 120W + 120W
• Efficiency Ratio: Greater than 90%
• Number of Channels: Two-channel with high and bass adjustment
• Input Interface: DC5.5*2.1
• Color: Blue
• Material: Metal
• Size: 98 x 80 x 18 MM

Package Includes

• 1 x Amplifier Board
