S-500-24 Power Supply

Technical Parameters

• Model: S-500-24
• AC Input Voltage Range: 110/220VAC
• Input Current: 0.25A/115V, 0.5A/230V
• AC Impulse Current (Cold-start): 10.5A/115V, 19A/230V
• DC Output Voltage: 24V
• DC Output Power: 500W
• Rated Output Current: 20A
• Output Voltage Error: ±1%
• Efficiency: 85%
• Wave and Noise: 100mVp-p
• Inlet Stability: ±0.5%
• Load Stability: ±0.5%
• Overload Protection: 105% - 150% of rated power, with automatic recovery
• Vibration: 10-500Hz, 2G, 10min./1cycle, for 60min each axis
• Cooling Method: Fan-assisted cooling
• Working Temperature and Humidity: -20°C to 60°C, 20% to 90% RH (no frost)
• Storage Temperature and Humidity: -30°C to 85°C, 10% to 95% RH (no frost)
• Safety Standards: CE (EMC + LVD), FCC
• Dimension: 215 x 115 x 50 mm
• Weight: 0.85 kg

Features

• International AC input range
• High efficiency, low working temperature
• Short circuit, overload, and over-current protection
• 100% full-load burn-in test to ensure reliability
• Built-in EMI filter for low ripple noise
• Cost-effective and high reliability
• CE and FCC approved

Specifications

• LED switching power supply using pulse width modulation (PWM) for stability and efficiency
• Product interference compliant with EMC testing, ripple ≤ 50mV
• Efficiency above 80%, operational temperature ≤ 25°C
• Equipped with overvoltage protection, short-circuit protection, and overload protection
• Constant current output ensures stable power, enhances LED lighting effects and longevity
• Anti-interference design for prolonged LED strip life, minimizing lighting decline

Package Includes

• 1 x Power Supply
