Full-Wave Band Radio Receiver

Experience the superior quality of our full-wave band radio receiver, featuring a 0.96 inch OLED display for a clear and customizable viewing experience. This versatile device supports a wide range of features and is perfect for both commercial and ham radio enthusiasts.

Key Features

• 0.96 Inch OLED Display: Easily view FM band, AGC on/off, and MONO settings.
• Auto-Hold Settings: Retains your settings even after a power failure.
• Built-In Battery: Equipped with a 3.6V, 600mAH polymer lithium battery for stable and sustainable power.
• USB Recharging: Simple recharging with the included Type-C cable.
• Audio Output Support: Compatible with 3.5mm earphones and includes 4ohm speaker 2W output.
• SMA Antenna Interface: Printed circuit board retains SI4735 package for customizable chip replacement and software compatibility.
• Pre-Configured Bands: Offers 22 commercial and ham radio bands for unrestricted use.
• Frequency Modes: Configure FM, AM (MW and SW), and SSB (LSB and USB).
• Audio Bandwidth Filter: Available settings include 0.5, 1, 1.2, 2.2, 3, and 4Khz.
• BFO Control & Frequency Step Switch: Offers switching options of 1, 5, and 10KHz.

Specifications

Material: Printed circuit board

Supported Bands

• FM: 8400 - 10800
• LW: 100 - 510
• MW: 520 - 1720
• Various SW bands including 160m, 80m, 40m, 20m, and more.

Dimensions & Weight

Item Size: 89 x 107 x 41mm / 3.50 x 4.21 x 1.61in

Item Weight: 205g / 7.23oz

Package Size: 173 x 122 x 52mm / 6.81 x 4.80 x 2.05in

Package Weight: 250g / 8.82oz

Packing List

• 1 x Radio Receiver
• 1 x Antenna
• 1 x Type-C Cable
