Talkpok A36plus Multi-Function Dual Band Walkie Talkie: GMRS HAM Radio, Color Display, 512 Channels, 5W, AM AIR VHF UHF, 7-Band Receiver

Talkpod A36plus Multi-Band Portable Transceiver

Overview

The Talkpod A36plus is a versatile multi-band portable transceiver. It features a 1.44" color display and a rugged, compact design for simple operation and exceptional performance. With a 5W RF output in the 144 and 430 MHz bands, it offers dual-watch capability, supporting V/V, U/U, and V/U modes, as well as DV/DV mode. The device includes a VHF/UHF airband and FM broadcast receiver, with a powerful 1000mW audio output for clearer communication. For added safety, an SOS button on the top panel gives quick access to a calling channel. It is also IP54 rated for dust-tight and water resistance.

Main Features

• Color display with multilingual UI
• Private call with scrambling for advanced communication security
• Flexible frequency management with smart frequency breaking and OTA replication
• Edit independent identity ID and personalized names for channels
• Each A/B section supports up to 256 channels, totaling a maximum of 512 stored channels
• Supports DTMF, 2 Tone, 5 Tone, and cross frequency span communication
• MDC1200 and other call end tones
• Compatible with Type-C boost charger, desktop charger, six-unit charger, and vehicle charger
• Receives NOAA weather channel, real-time weather alerts, ensuring safe travel

General Specifications

Model Number

A36plus

Frequency Coverage

TX: 136-174, 220-260, 350-390, 390-470, 470-520 MHz
RX: 136-174, 220-260, 350-390, 390-470, 470-20 MHz
FM Broadcast: 65–108 MHz
AM Broadcast: 108-136 MHz

Number of Channels

256 channels

Type of Emission

F2D, F3E (FM)

Frequency Stability

±2.5 ppm (–20°C to +60°C based on 25°C)

Power Supply Requirement

7.2 V DC nominal

Current Drain

Tx High: Less than 1.7 A
Rx Max. audio: Less than 600 mA

Antenna Impedance

50 Ω (SMA)

Operating Temperature Range

–20°C to +60°C

Dimensions (H×W×D)

108x52x28 mm (with TBL21)

Weight (Approximate)

210 g (with TBL21 and antenna)

Transmitter Specifications

Output Power

5 W, 2.5 W, 0.5 W

Max. Frequency Deviation

±5.0 kHz/±2.5 kHz (W/N)

Spurious Emissions

Less than –60 dB (High, Mid), Less than –13 dBm (Low)

External Microphone Connector

3-conductor 2.5 mm (1⁄10ʺ)/2.2 kΩ

Receiver Specifications

Receiver Sensitivity

Less than 0.18 μV (at 12 dB SINAD)

Squelch Sensitivity

Less than 0.18 μV (at squelch threshold)

Adjacent Channel Selectivity

More than 55 dB (FM, 25 kHz)
More than 50 dB (FM Narrow, 12.5 kHz)

Spurious Response

More than 60 dB

Audio Output Power

Internal SP: 1000 mW (typical)
External SP: 450 mW (typical) (at 5% distortion, 8 Ω load)

Package Includes

• 1 x Talkpod A36plus with Antenna
• 1 x Battery
• 1 x Lanyard
• 1 x Back Clip
