Mini DC-DC Boost Converter 7W, 2.6-5.5V to 5V/6V/9V/12V Voltage Regulator Module

DC-DC Boost Converter Module

Discover the innovation in power conversion technology with our DC-DC Boost Converter Module. This compact yet powerful module is designed to enhance your devices with precision and reliability.

Key Features:

• Working Frequency: 1MHZ
• Efficiency: Up to 93% (typically 84%-91%)
• Quiescent Current: 190μA
• Current Limit Program: 0.5-2.5A (Default 1.8A)
• Dimensions: 21 x 11 x 4mm
• Weight: 1.5g
• Protection Features:
  • Over Current Protection (OCP)
  • Over Voltage Protection (OVP)
  • Short Circuit Protection (SCP)
  • Over Temperature Protection (OTP)

Output Specifications:

Pin Descriptions:

• Vi: Input Positive (+)
• GND: Input and Output Negative (GND/-)
• Vo: Output Positive (+)

Applications:

This versatile module is ideal for:

• Battery-powered equipment
• Instrumentation and multimeters
• Breadboard, STM32, LCD, LED
• Small power motors
• Cameras (PTZ, IP) and webcams
• Toy cars and boats
• Model aircraft
• Power banks
• Solar power systems
• WiFi routers
• PLC and RS485 devices
• Lithium battery power supply equipment

Attention:

This is a DC-DC voltage converter module. Please consider the following:

1. Input voltage must not exceed the maximum input range.
2. Output power must not exceed the maximum load for extended periods.
3. Input power must be greater than output power due to module power consumption.

FAQ:

Q: Why is the output voltage lower than the nominal voltage?
A: The input power supply might be too low. Test the input voltage with a multimeter to ensure it is within the appropriate range.

Package Includes:

• 1 x 7W Mini DC-DC Boost Step-Up Converter (2.6-5.5V to 5V, 6V, 9V, 12V)
