Hantek DSO5072P Digital Storage Oscilloscope

Model: DSO5072P

Overview

The Hantek DSO5072P is a high-performance, digital storage oscilloscope with advanced features and a user-friendly interface, making it a perfect tool for both professionals and hobbyists.

Key Features

  • Bandwidth: 70MHz
  • Real-Time Sample Rate: 1GSa/s
  • Display: Large 7-inch color TFT LCD with WVGA (800x480) resolution
  • Record Length: Up to 40 Kbytes
  • Trigger Modes: Edge, pulse width, line selectable video, slope, overtime, etc.
  • Connectivity: USB host and device
  • Multiple automatic measurements for convenience
  • Four math functions including standard FFTs for signal analysis
  • Software provided for real-time PC analysis
  • Optional VGA connectivity

Specifications

Acquisition

  • Sample Rate: Real-Time Sample: 1GS/s

Inputs

  • Input Coupling: AC, DC, GND
  • Input Impedance: 1MΩ±2% // 20pF±3pF

Horizontal System

  • Sample Rate Range: 500MS/s - 1GS/s
  • Waveform Interpolation: (sin x)/x
  • Record Length: 40 Kbytes
  • Time/Div Range: 4ns/div to 40s/div
  • Accuracy: ±50ppm over any ≥1ms time interval

Vertical System

  • Vertical Resolution: 8-bit, all channels sampled simultaneously
  • Position Range: 2mV/div to 10V/div
  • Bandwidth: 70MHz
  • Rise Time at BNC (typical): 5ns

Trigger System

  • Types: Edge, Video, Pulse, Slope, Over time, Alternative
  • Sources: CH1, CH2, EXT, EXT/5, AC Line

Display

  • Type: 7-inch 64K color TFT, liquid crystal
  • Resolution: 800x480 pixels
  • Contrast: Adjustable (16 levels) via progress bar

Power Supply

  • Voltage: 100-120VAC RMS (±10%), 45Hz to 440Hz, CAT II; 120-240VAC RMS (±10%), 45Hz to 66Hz, CAT II
  • Power Consumption: Low

Environmental

  • Operating Temperature: 32°F to 122°F (0°C to 50°C)
  • Nonoperating Temperature: -40°F to 159.8°F (-40°C to +71°C)
  • Humidity: ≤90% relative humidity up to 104°F (40°C), ≤60% from 106°F to 122°F (41°C to 50°C)
  • Altitude: Operating below 3,000m, non-operating below 15,000m

Mechanical

  • Dimensions: Length 385mm, Width 200mm, Height 245mm
  • Weight: 3.5kg (with packaging), 2.08kg (without packaging)

Package Includes

  • 1 x DSO5072P Digital Oscilloscope
  • 1 x Power cord
  • 2 x Probe
  • 1 x USB cable
  • 1 x CD-ROM
